JET-5310
The JET-5310 is an industrial-grade BOX PC supporting 11th Gen low-power CPUs with robust expandability. Designed for harsh environments, it delivers stable and efficient performance with multiple M.2 slots, RJ45 ports, and USB ports to support wireless connections and high-definition video devices. The JET-5310 uses high Tg wide-temperature PCB material, and its industrial-grade port protection effectively blocks static and surges, ensuring the safety of the system.
- •
- 11th Gen TGU series low-power CPU with a TDP of 15W
- •
- One DDR4 SO-DIMM slot, supporting up to 32GB
- •
- M.2 2280 Key-M, supporting SATA/nVME adaptive function
- •
- M.2 3042/3052 Key-B, supporting 4G/5G wireless connections
- •
- M.2 2230 Key-E, supporting WiFi/BT wireless connections
- •
- Standard version: Four Intel Fast Ethernet ports with 4kV surge protection
- •
- Standard version: Four USB 3.2 Gen 2 ports for connecting high-definition video equipment
- •
- Two display interfaces: HDMI + DP, supporting dual-mode operation
System | Processor | i3-1115G4/i5-1135G7/i7-1165G7/i7-1195G7/6305E / i3-1115G4E / i5-1145G7E/ i7-1185G7E |
Chipset | Intel Tiger Lake U SoC | |
BIOS | AMI UEFI BIOS | |
Memory | 1xDDR4 3200MHz SO-DIMM，up to 32GB | |
OS | Windows10, Linux | |
I/O interface | USB | 4xUSB 3.0, 2xUSB 2.0 |
Serial | 2xRS232/422/485 | |
GPIO | 8 bit digital I/O | |
LED | 1xPower, 1xHDD | |
Others | 1xCANBus 2.0, 1x I²C | |
Expansion | PCIe/M.2/Mini-PCIe | 1xM.2 Key-B3042/3052, support 4G/5G(PCIe x1,USB2.0)； 1xM.2 Key-E 2230 (PCIe x1, USB2.0) |
Graphics | Graphics Processor | Intel®UHD Gen.11 Graphics Engines |
Interface | 1xDP, up to 4096 x 2160 @60Hz 1xHDMI, up to 4096 x 2160 @60Hz | |
Storage | SATA/M.2/mSATA | 1xM.2 Key-M (2280,SATA/nVME) 1xSATA3.0（support 2.5” HDD/SSD) |
Audio | Audio IC | Realtek ALC897 |
Audio Interface | 1xMic-in, 1xLine-out（2 in 1） | |
Ethernet | LAN IC | 3x i226V, 1x i210AT |
Interface | 4xRJ45 | |
Power | Power Input | 12V to 36V, DC-in |
Power Interface | 2-Pole Phoenix DC plug in | |
Others | Watchdog Timer | 1 to 255 sec./min. per step |
TPM | Infineon SLB9670 supports TPM 2.0 | |
Mechanical | Dimensions | 200.4mm(L)×140.4mm(W)×52.7mm(H) |
Weight | 1.8KG N.W. | |
Mounting | Desk/Wall-mounting, Din rail mounting | |
Environment | Operating Temp. | -10~60℃w/ 0.7m/s airflow |
Storage Temp. | -40~85℃ | |
Humidity | 10%~85% Humidity, non-condensing | |
Shock | With SSD: 15G, IEC 60068-2-27, half sine, 11ms duration | |
Vibration | With SSD:2Grms, IEC 60068-2-64, random，5~500Hz，1 hr/axis |
