E098
The JEA-E098 is an edge gateway product based on the Intel Tiger Lake-U platform, offering robust performance and a rich interfaces with support for various expansion features. It is suitable for IoT, AI, and edge computing applications. The device provides multiple storage and network connectivity options, supports multiple display outputs, and features excellent scalability and compatibility.
- •
- Intel Tiger Lake-U
- •
- 2*DDR4 SO-DIMM
- •
- 2*M.2 SATA
- •
- 4*HDMI，support splicing
- •
- WIFI6、4G/5G expansion
- •
- LoRa/Zigbee/Bluetooth expansion
- •
- AI accelerator card expansion
- •
- 4*USB，6*COM
- •
- 4*Gigabit Ethernet，2*Gigabit SFP
- •
- TPM/TCM(Encryption module)
System | CPU | Intel®Tiger Lake U CPU，TDP Max 15W |
GPU | SOC | |
NPU | 2 x M.2 2280 Key M for AI NPU Module，Max 16TOPS 1 x SODIMM for Nvidia Jetson NX Module，Max 21TOPS | |
Memory | 2 x SODIMM DDR4 3200Mhz，Up to 64GB | |
Expansion | Interface | 1 x M.2 (KEY M 2280) for NVME SSD or AI NPU Module 2 x M.2 (KEY M 2280) for SATA SSD 1 x M.2 (KEY B 3052/3042) for 4G/5G Module |
Graphics | Graphics Processor | Intel®UHD Graphics |
Interface | HDMI1.4 Out，Max resolution up to 4096x2160@30Hz | |
Storage | Storage Device | M.2 SSD |
GNSS | GNSS | Non-support |
Audio | Audio Codec | ALC897 |
Interface | 1 x 3.5mm Line Out，1 x 3.5mm Mic In | |
Network | Ethernet | 2 x GbE RJ45 （optional FSP） 4 x GbE RJ45 (option POE） |
WIFI | 1 x M.2 2230 with PCIe and USB2.0 for WIFI/BT Module | |
I/O | LED | 1 x Power LED，1 x HDD LED，1 x 4G/5G LED，1 x WIFI LED |
USB | 3 x USB2.0 TYPE-A，1 x USB3.0 TYPE-A | |
Serial | 6 x COM（RS323/RS485） | |
Others | 1 x 20 Pole Phoenix GPIO （8GPI and 8GPO） | |
Power | Power Input | 19V DC-In |
Power Interface | 4Pin DC JACK | |
Other | OS Supports | Linux/Windows10/Windows11 |
Watchdog | Support | |
TCM/TPM | Onboard TCM IC | |
Antenna | 6 x ANT（WIFI/4G/5G/Lora） | |
Dimension | Dimensions | 268mm(L)×200mm(W)×53.7mm(H) |
Mounting | Desk/Wall-mounting | |
Environment | Operating Temp. | 0~40℃ |
Humidity | 10%~90% Humidity, non-condensing | |
Storage Temp. | -20~70℃ | |
Humidity | 5%~95% Humidity, non-condensing |
