S088
Designed with the Rockchip RK3588 platform, featuring a quad-core Cortex-A76 plus quad-core Cortex-A53 processor, a standard OPS reference and 4K display, it is ideal for conference solutions, education and digital signage applications.
- •
- Based on Rockchip RK3588 processor
- •
- The whole machine adopts fanless design
- •
- Support LPDDR4x 4GB/8GB memory
- •
- Support eMMC5.1 16GB/32GB/64GB/128GB storage
- •
- Display: 1 x HDMI-Out, 1 x HDMI-In, 1 x HDMI-Out (80pin)
- •
- Support WIFI-BT/4G mobile network
- •
- Support 1000M Ethernet RJ45 interface
- •
- Support Android 13 operating system
CPU | CPU | RK3588 |
TDP | 7 W | |
Display | Graphic card | Mali-G610 MC4 |
Multi displays | Support Dual displays | |
Interface | 1 x HDMI-Out 4K@60Hz, 1 x HDMI-In 4K@60Hz; 1 x 80pin HDMI-Out 4K @60Hz | |
Network | Lan IC | 1 x LAN IC |
Lan Interface | 10/100/1000Mbps | |
Lan Connector | 1 x RJ45 Port | |
Wireless Type | M.2 Key E 2230 Connector | |
Wireless Interface | Mini PCIe WiFi/BT Module | |
4G/5G | Optional | |
I/O interface | Display | 1 x HDMI-Out 4K@60Hz, 1 x HDMI-In 4K@60Hz |
USB | 4 x USB3.0 Type-A, 1 x Type-C | |
Button | 1 x PowerButton, 1 x Clear CMOS Key | |
Slot | 1 x SIM Card Slot 1 x Micro SD Card Micro SD Card | |
AUDIO | 1 x Line Out ; 1 x MIC-In | |
POWER | 1 x 2.5/5.5 DC-IN Connector | |
JAE | 1 x 80PIN jJAE Support 1 x HDMI2.0 4K60Hz output 2 x USB2.0, 1 x USB3.0, 1 x TTL, other control signals | |
System | Memory | LPDDR4x 4G/8G |
Storage | OnboardEMMC5.1 16GB/32GB/64GB/128GB | |
OS | Android13 | |
WatchDog | Support | |
Auto Power On | Yes | |
RTC | Power On/Off at specific time ,a week | |
Power Input | 12~19V DC IN, 2.5/5.5 DC Jack & JAE 80p | |
Dimension | 119mm(L) x 180mm(W) x 30mm(H) | |
Operating Temp. | -5~45℃ | |
Operating Humidity | 10%~90% non-condensing | |
Storage Temp | -20~70℃ | |
Operating Humidity | 10%~90% non-condensing |
Obtain comprehensive product information. For various needs from product definition to software and hardware development, we will arrange product engineers to serve you as soon as possible.
