SYS-6029C
The SYS-6029C series is based on the Intel® C246 high-performance server chipset and is newly designed to support Xeon® E-2100/2200 series processors as well as Intel® 8th/9th Gen Core™ i3/i5/i7 series processors. From its exterior design to internal structure, this new server reflects the company’s commitment to its business philosophy of technology, innovation, and environmental protection, aiming to provide customers with a high-performance, high-reliability, low-power-consumption 2U server with excellent heat dissipation. Whether deployed in enterprise-class data centers or for developing enterprise applications, the product offers a variety of flexible configuration options to better meet the growing server demands of customers and delivers reliable hardware support for data storage, big data processing, virtualization, and other applications, making it an ideal choice for large-scale industries, enterprises, and government users with high requirements for stability and practicality.
- •
- Stable and innovative bottom design, with accurate airflow guidance and fan adjustment mechanism, create a stable and reliable model
- •
- Supports Xeon E-2100/2200 series processors, Intel® 8th/9th Gen. Core i3/i5/i7 series processors
- •
- Adopts the latest DDR4 memory technology and supports four DDR4 DIMM slots, up to 128 GB UDIMMs. The maximum support frequency is 2666MHz, and the memory read and write rate is significantly improved. Supports one standard PCIe 3.0 x8 (x16 slot), one standard PCIe 3.0 x8, and one standard PCIe 3.0 x4 (x8 slot) for flexible expansion. Support hardware monitoring, can remotely monitor the host power supply, voltage, temperature, fan and other hardware working status
- •
- Supports up to 12 3.5-inch (2.5-inch) hot-swappable hard drives with 6GB SATAIII storage. Support 1 M.2 PCI-E 3.0x2 (2242/2280)
- •
- Supports four gigabit RJ45 electrical ports (Intel I210) and one gigabit RJ45 IPMI dedicated management network port, providing enterprise applications with a variety of network transmission and communication and remote device management solutions.
系统主控 | CPU型号 | 1个 Single Socket H4 (LGA 1151) ，Coffee Lake，支持Intel® Xeon® processor E-2100/E-2200 , Intel® 8th/9th Gen. Core™ i3/i5/i7 series,Intel® Celeron® and Intel® Pentium®系列处理器，TDP 95W |
桥片 | C246 | |
内存 | 类型 | 4 x DIMM 插槽，最大支持128GB 2666/2400/2133/1866/1600MHz ECC /non-ECC |
显卡 | 芯片/接口 | ASPEED AST2400 BMC ，1个VGA接口， 1 x HDMI(CPU集显) |
存储 | 外置 | 支持12个3.5英寸 6G SATAIII 前置热插拔硬盘，2个2.5英寸后置硬盘（可选）支持Raid 0,1,5,10 |
M.2 | 支持1个M.2 PCI-E 3.0 x2（2242/2280) | |
千兆网络 | 网卡IC | Intel i210企业级千兆网络控制器 |
网卡带宽 | 4个千兆网络，支持支持10/100/1000Mbps | |
网卡连接器 | 2个双层RJ45接口 | |
IPMI 管理接口 | 类型 | 1个标准RJ45，10/100/1000Mbps网络接口 |
USB | USB 3.0 | 4个USB 3.0（后 IO） |
USB 2.0 | 2个USB 2.0（前IO） | |
串口 | 串口 | 1 x COM接口 |
PCIe扩展 | PCIe扩展 | 1个标准PCIe 3.0 x8（x16插槽），1个标准PCIe 3.0 x8，1个标准PCIe 3.0 x4（x8插槽） |
后窗指示灯 | 后窗指示灯 | 1个带灯UID开关 |
前面板 | 开关 | 1个电源开关；1个复位开关 |
指示灯 | 1个电源指示灯；1个风扇异常指示灯；1个硬盘活动指示灯；2个网络指示灯 | |
电源 | 电源输入 | 1+1冗余550W电源 |
风扇 | 风扇 | 3个8038风扇，支持热插拔； |
尺寸 | 尺寸 | 尺寸：444mm（宽）87.6mm（高）670mm（深） |
温度湿度要求 | 温度 | 工作温度： 0°C ~ 35°C；存储温度 -40°C to 70°C |
湿度 | 工作湿度要求： 8% ~90% 无凝结；非工作湿度要求： 5%~95%无凝结 | |
安装套件 | 滑轨 | 支持滑轨（滑轨选配） |
