SYS-6028R
The SYS-6028R-S08 series is built with the Intel® C612 high-performance server chipset and is based on Intel® Xeon® E5-1600 v3/v4 and E5-2600 v3/v4 series processors. From the exterior design to internal materials, this new Xeon E5 server reflects the company’s commitment to its business philosophy of technology, innovation, and environmental protection, aiming to provide customers with a high-performance, high-reliability, low-power-consumption 2U 8-disk server with optimal heat dissipation. Whether deployed in enterprise-class data centers or for developing enterprise applications, the product offers a variety of flexible configuration options to better meet the growing server demands of customers and delivers reliable hardware support for data storage, big data processing, virtualization, and other applications, making it an ideal choice for large-scale industries, enterprises, and government users with high requirements for stability and practicality.
- •
- The stable and innovative underlying design, combined with accurate airflow guidance and fan regulation mechanism, creates a stable and reliable model. Based on Intel®C612 high-performance server chipset, it supports one Intel® Xeon ® E5-1600 v3/v4, E5-2600 V4/V3 series high-performance processor (Grantley: Haswell/Broadwell). Provides eight DDR4 DIMM slots (4 channels /CPU, 4-DIMM slots /CPU). Supports DDR4 ECC RDIMM/LRDIMM/3DS LRDIMM. Maximum support frequency 2400MHz
- •
- Supports a maximum capacity of 1TB, significantly improving the memory read/write rate. Supports four PCI-E 3.0 expansion slots for flexible expansion
- •
- Supports up to eight 3.5/2.5-inch SATA3/SAS3 hot swappable hard drives (12Gb/s expansion backplane)
- •
- Optional rear 2 x 2.5-inch Nvme/SAS3/SATA3 hot-swappable hard disks. Optional array card, supporting RAID0/1/10/5/6/50/60/1E (Optional RAID card cache protection module). Supports two gigabit RJ45 ports (Intel i210) and two 10-gigabit SFP+ ports (Intel 82599ES). 1 gigabit RJ45 IPMI dedicated management network port
- •
- ASPEED AST2400 supports management features such as IPMI2.0, SOL, KVM Over IP, virtual media, and device health monitoring.
System Control | CPU Model | Intel® Xeon® E5-1600 v3/v4, E5-2600 V4/V3 series processors, Grantley: (Haswell/Broadwell); TDP 160W; QPI (9.6 GT/s) |
Number of CPUs | 1 x Socket R3 (LGA 2011) | |
Chipset | Intel® C612 chipset | |
Memory | Type | 8 * memory slots (4-channel/CPU, 4-DIMM slots/CPU), supports up to 1TB 3DS LRDIMM Supports 2400/2133/1866/1600MHz ECC DDR4 RDIMM, LRDIMM, 3DS LRDIMM |
Graphics | Chip/Interface | ASPEED AST2400 BMC, 1 * VGA port |
Storage | External | Supports 8 * 3.5/2.5-inch SATA3/SAS3 hot-swappable hard drives (12Gb/s expansion backplane), Optional rear-mounted 2 x 2.5-inch Nvme/SAS3/SATA3 hot-swappable hard drives |
RAID controller | PCH C612 integrates 10 * SATA3 6Gb/s interfaces, supports Raid0,1,5,10 (6 7-pin SATA (iSATA) + 4 7-pin SATA (sSATA)) Optional RAID card, supports RAID0/1/10/5/6/50/60/1E (optional RAID card cache protection module) | |
Gigabit Network | Network card IC | Intel i210 Enterprise-Class Gigabit Network Controller; Intel 82599ES Dual Port Enterprise-Class 10G Network Controller |
Network Card Bandwidth | 2 * Gigabit networks, supports 10/100/1000Mbps; 2 * 10G networks, supports 10/1GbE | |
Network Card Connector | 2 * single-layer RJ45 ports; 2 * dual-layer SFP+ ports; | |
IPMI management interface | Type | 1 * standard RJ45, 10/100/1000Mbps network interface |
USB | USB 3.0 | 2 * USB 3.0 (rear IO) |
USB 2.0 | 2 * USB 2.0 (rear IO), 2 * USB 2.0 (front), 1 * USB 2.0 (internal TYPE A) | |
Serial port | Serial port | 1 x COM port, 1 x serial port header |
PCIe Expansion | PCIe Expansion | 4 * Standard PCIe 3.0 * 8 slot |
Rear window indicator lights | Rear window indicator lights | 1 * illuminated UID switch |
Front panel | Switch | 1 * power switch; 1 reset switch |
Indicator Lights | 1 * power indicator light; 1 * abnormality indicator light; 1 * hard disk activity indicator light; 2 * network indicator lights | |
Power source | Power input | Optional CRPS 550W/800W/1300W 1+1 redundant power supply |
Fan | Fan | 3 * 8038 fans, hot-swappable; |
Dimensions | Dimensions | Dimensions: 670mm (D) * 444mm (W) * 87.6mm (H) |
Temperature / humidity requirements | Temperature | Operating temperature: 10°C to 35°C; Storage temperature: -40°C to 70°C |
Humidity | Operating humidity: 8% to 90% non-condensing; storage humidity: 5%- 95% with no condensation | |
Installation kit | Rails | Supports rails (optional) |
