N331-16
This N331-16 supports Intel Raptor Lake platforms, delivering smooth performance and low power consumption. Designed for everyday consumers, it’s ideal for work, study, and entertainment, with reliable connectivity and long battery life.
- •
- Intel Raptor Lake Platform
- •
- 16” FHD 1920*1200 IPS or QHD 2560*1600
- •
- A Metal, CD Plastic
- •
- 1x M.2 SSD PCIE4.0X4
- •
- 1x onboard 12*16 WIFI/BT
- •
- 1x HDMI(TYPE A)
- •
- 3x USB 3.2
- •
- 1x Type-c (Data + DP + Charging)
- •
- WIN11/Linux OS
Processor | CPU | Intel® Raptor lake-U/P/H, TDP 45W Option ADL U/P/H |
BIOS | AMI UEFI BIOS | |
Graphic card | Indicate | Intel® Iris® XE Graphics、Intel® UHD Graphics |
Multi displays | Support 3 displays | |
Interface | 1 x HDMI , 1 x Type-c | |
LCD | SIZE | 14inch FHD 1920*1200 IPS or WQXGA 2240*1440 |
Memory | Type | 8GB/16GB/32GB LPDDR5 |
MAX Capacity | 32GB | |
LAN Interface | Lan IC | RT8111M RJ45 |
Wireless | WIFI Standard | Support WiFi 802.11b/g/n/ac/ax |
Speaker | Type | Built-in stereo speakers 8Ω/1.0W*2 |
Camera | Type | 1080P(2M) w/shutter door+DMIC*2 |
Storage | Type | Support SSD |
IO | 1 * M.2 2280 PCIe4.0×4 | |
I/O Interface | Left size | 1 * DC IN JACK，1 * HDMI1.4（4096 x 2304 @ 60Hz），1 * USB3.2 （GEN1），1*Type-c（PD+DP+Charging） |
Right size | 1*Kingston 1*RJ452*USB3.2（GEN1）,1*3.5mm AUDIO JACK，1*Micro SD | |
Keyboard | Input Device | US&UK（Support backlight) |
Operating System | OS | WINDOWS 11/LINUX |
TPM | Optional | |
Battery | Capacity | 58Wh（3S1P） |
Power adapter | Power Input | DC or Type-C GaN 100W 20V/5A ，(RPL U/P:65W) |
Product Form | Form Factor | Notebook , 180° ；A metal，CD Plastic |
Dimensions | 314.4*219.0*18.3mm | |
Weight | ~1.49kg（without adapter) | |
Environment | Operating Temp. | 0~45℃ |
Operating Humidity | 10%~90% non-condensing | |
storage Temp. | -20~70℃ | |
Non-Operating humidity | 5%~95% non-condensing |
From initial concept to final development, our expert product engineers deliver tailored hardware and software solutions—ready to assist you immediately.
