N521-14
The N521-14 supports the Intel Alder Lake-N platform, offering smooth performance and low power consumption. Designed for everyday consumers, it is ideal for work, study, and entertainment, featuring reliable connectivity and long battery life.
- •
- Intel ADL-N N100/N300 &TWL-N Option
- •
- 14.1inch FHD 1920*1080 IPS
- •
- A/C/D Metal
- •
- 1x M.2 2280 SSD slot
- •
- 1x WIFI6 M.2 2230
- •
- 2x USB3.2(Gen1 ,5Gbps)
- •
- 2x Type-c (Data + DP + Charging)
- •
- 1x Micro SD
- •
- WIN11/Linux OS
Processor | CPU | Intel ADL-N N100 |
BIOS | AMI UEFI BIOS | |
Graphic card | Indicate | Intel® UHD Graphics |
Multi displays | Support 3 displays | |
Interface | 2 x Type-c | |
LCD | SIZE | 14.1 inch FHD 1920*1080 IPS |
Memory | Type | 8GB/16GB LPDDR5 |
MAX Capacity | 16GB | |
LAN Interface | Lan IC | NA |
Wireless | WIFI Standard | Support WiFi 802.11b/g/n/ac/ax |
Speaker | Type | Built-in stereo speakers 8Ω/1.0W*4 |
Camera | Type | 1080P(2M) w/o shutter door+DMIC*2 |
Storage | Type | Support SSD |
IO | 1 * M.2 2280 PCIe4.0×4 | |
I/O Interface | Left size | 1 * USB3.2 （GEN1），2*Type-c（PD+DP+Charging） |
Right size | 1*Audio Jack 1 *USB3.2（GEN1）, 1*Micro SD | |
Keyboard | Input Device | US&UK（Support backlight) |
Operating System | OS | WINDOWS 11/LINUX |
TPM | Optional | |
Battery | Capacity | 7.6V/5250mAH 39.9wh （3S1P） |
Power adapter | Power Input | Type-C GaN 45W 20V/2.25A |
Product Form | Form Factor | Notebook , 180° ；A/C/D metal |
Dimensions | 322.2x209.2x13.35mm | |
Weight | ~1.25kg（without adapter) | |
Environment | Operating Temp. | 0~45℃ |
Operating Humidity | 10%~90% non-condensing | |
Storage Temp. | -20~70℃ | |
Non-Operating humidity | 5%~95% non-condensing |
