AIoT7-GMLi
Adopts Intel J4125 board mount CPU, rich interface and bus, supports serial port power sweep gun, supports TTL level serial port device, supports digital quantity switch control interface, can be used for POS, lottery betting station, gaming machine, self-service equipment, can also meet some industrial automation applications.
- •
- Onboard Intel Gemini Lake 4 Core J4125 2.0~2.7GHz CPU
- •
- 1 DDR4 SO-DIMM slot, 8GB max
- •
- 3 Display port/ 2 SATA / 2 GbE / 10USB / 6COM / 2 PCIe
- •
- 6 RS232, COM1 supports RS485, and COM2 & 3 supports serial power supply
- •
- 2 Intel i226V high-speed Ethernet ports
- •
- 1 mPCIe (with SIM support for 4G), 1PCIe x1 slot
- •
- One M.2 Support for SSD (2242 / 2280)
- •
- Support digital audio output with power amplifier
- •
- Support cassette control interface
CPU | Onboard Intel Gemini Lake 4 Core J4125 2.0~2.7GHz CPU |
Chipset | IntelGemini Lake SOC |
Memory | 1 DDR4 SODIMM memory slot, 8GB max |
Display controller | Intel CPU Integrated display controller |
Display interface | Three-display port: VGA + HDMI + LVDS / eDP, support triple-display VGA maximum resolution 1920x1200@60Hz; HDMI maximum resolution 4096x2160@30Hz eDP resolution 4096x2160@ 60Hz; LVDS best resolution: 1920 * 1080 |
Storage | 1 SATA 3.0, 1 M.2 2242 / 2280 support SSD of the SATA protocol |
Audio | Rear IO : Mic-in, Line-out, Support chassis front panel audio, support amplifier audio output (4Pin wafer) |
Network | 2 RJ45 Gigabit Ethernet ports, Intel i226V |
USB | 2 rear IO USB（2 x USB 3.0 Type-A) 8 intenal USB2.0（via header) |
Parallel/I²C/SMBus | 1 Parallel , 1 4Pin SMBus |
Serial port | COM1 supports RS232 / 485, and COM2-COM6 supports RS232 COM2 & COM3 supports Pin 9 5/12V power supply, and COM3 optional TTLTTL signal |
Keyboard & mouse | PS/2 keyboard/mouse via pin-header |
Digital I/O | 8-digit I/O, providing power and ground, + 5V level 1 4Pin CashDrawer control interface |
LPC/eSPI | 1 LPC bus |
TPM interface | Non |
Power supply | DC-Jack single 12V input, optional 2Pin Phoenix connector input DC Out power supply: 12V and 5V@500mA |
Expansion bus | 1 PCIe3.0 x 1 expansion slot 1 Mini-PCIe extension (with SIM holder for 4G module) |
Operating temperature and humidity | 0~60℃, 10%~90%, no condensation |
Non-operating temperature and humidity | -40 to 80℃, 10% ~90%, no condensation |
Watch Dog | 255 level programmable seconds / minutes, support timeout interruption or system reset |
BIOS | AMI UEFI BIOS |
Operating System | Windows10，Windows11，Linux Ubuntu 22.04 |
PCB dimensions (L*W) | 170mm*170mm |
