N121-14
This N121-14 supports Intel® Alder Lake (ADL) or Twin Lake (TWL) platforms, delivering smooth performance and low power consumption. Designed for everyday consumers, it’s ideal for work, study, and entertainment, with reliable connectivity and long battery life.
- •
- INTEL ADL & TWL Platform
- •
- 14inch 1920x1200 16:10
- •
- 1 x M.2 SSD slot
- •
- 1 x M.2 Key-E ，Support WIFI/BT
- •
- 1 x HDMI 1.4(TYPE A)
- •
- 3 x USB 3.2
- •
- 1 x Type-c full function
- •
- Support WIN11/Linux
Processor | CPU | Intel® Alder lake-N or Twin Lake-N (TDP. 6W~15W) |
BIOS | AMI UEFI BIOS | |
Graphic card | Indicate | Intel® UHD Graphics or Intel® Graphics |
Multi displays | Support 3 displays | |
Interface | 1 x HDMI , 1 x Type-c | |
LCD | SIZE | 14inch 1920x1200 16:10 |
Memory | Type | 8GB/16GB LPDDR5 4800MHz |
MAX Capacity | 16GB | |
LAN Interface | Lan IC | NA |
Wireless | WIFI Standard | 1 x M.2 Key-E WIFI/BT ，Support WiFi 802.11b/g/n/ac/ax |
Speaker | Type | 2 x8Ω/1.0W |
Camera | Type | 1080P(2M) w/shutter door+DMIC*2 |
Storage | Type | Support SSD |
I/O | 1 x M.2280 PCIe3.0×4/SATA | |
I/O Interface | Left | 1xDC IN JACK, 1x HDMI1.4, 1 x USB3.2 （GEN1)1 xType-c（full function）, 1 xKingston |
Right | 2 x USB3.2（GEN1），1*3.5mm AUDIO JACK，1*Micro SD | |
Keyboard | Input Device | US |
Operating System | OS | WINDOWS 11/LINUX |
TPM | Optional | |
Battery | Capacity | 6000mah(2S1P) |
Power adapter | Power Input | 12V3A DC IN |
Product Form | Form Factor | Notebook , 180° ；Full Plastic |
Dimensions | 319.2x230.8x18.1mm | |
Weight | ~1.49kg（without adapter) | |
Environment | operating Temp. | 0~45℃ |
Operating Humidity | 10%~90% non-condensing | |
storage Temp. | -20~70℃ | |
Non-Operating humidity | 5%~95% non-condensing |
